Smart Wi-Fi Outdoor/ Indoor Plug (2 EU type AC Outlets) Add Intelligence to Power Sockets

SP-1122WTO

  • Smart Wi-Fi outdoor/indoor plug (2 EU type AC outputs)
  • Add and control multiple devices at once with one App
  • Remotely control home appliances from anywhere
  • Separately control timing, countdown and all outputs with the EdiSmart Pro App
  • Easily share devices among family members
  • Voice control via Amazon Alexa/ Google Assistant/ Apple Siri
  • Easily and quickly connect EdiSmart Pro App to devices
  • iOS supports Widget and Apple Watch
  • Made for semi-outdoor
​
Get EdiSmart Pro app, Alexa Skills, Google Actions from:

​
Share


Intelligent Home

Our Smart Plug EdiSmart Pro home management App can monitor, control and s​chedule all of the electronic devices connected to Smart Plugs around your home.

Schedule and Save

Program intelligent schedules to make your home/office smarter and more energy efficient. Schedule your lamp, heater and 4 USB powered devices – Smart Power Strip can schedule anything just the way you like it!

Easy Setup

Setup couldn’t be any easier and is all done on your smartphone or tablet.

Share


SPECIFICATIONS

HARDWARE
Power Output 2 x Smart AC outlet
Receptacle Style: EU type( RG-02)
100-240VAC, 50Hz/60Hz
Total Max. 2300W, Max.10A
Button Power button
LED Indicator Red light: paring or Wi-Fi connection status
Green light: AC output on/off
Antenna Type Internal antenna
Power Input 100-240VAC, Max.10A ,50Hz/60Hz,
JT003 plug
Power Consumption <0.3W(Standby Mode)
Dimensions 153(W) x 80(D) x 57 (H) mm
Weight 450g
Cable Length 30cm
WIRELESS
Standards IEEE 802.11 b/g/n
Frequency Band 2412 - 2472MHz (Subject to local regulations)
Max. RF output power Wi-Fi (2.4G): 9.93dBm2
Type of Modulation Wi-Fi: DQPSK, DBPSK, DSSS, CCK and OFDM
Antenna Gain Wi-Fi (2.4G): 1dBi
FUNCTION
Management EdiSmart Pro App with for iOS 9 or Android 4.1 or above smart mobile devices
App Function Remote control to switch on/off the connected home appliances
Schedule your connected home appliances on/off in advance
Sharing the home appliances control to your family
Other Function Auto recovery when encountered a power outage without reset
Safety design with surge protection and over  voltage to protect the conneced devices demanaged or over temperature
OTHERS
Certification CE, RoHS
Environmental Condition Operating Temperature: -10°C~55°C
Storage Temperature: -20°C~60°C
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 10%~95% non-condensing
Installation App setup
System Requirement Smart mobile device with iOS 9 or Android 4.1 or above OS
2.4GHz Wi-Fi network
Package Content Smart Wi-Fi Power Strip
Quick Installation Guide


*Must be in well ventilated semi-outdoor spaces such as eaves of a house, verandah, balcony, porch, covered patios, etc..
*Must not be installed in locations that are subject to extreme weather conditions such as typhoon, heavy rain or dust storm; or it must be sheltered from the conditions.
*Must not be installed in locations that are subject to extremes of humidity or temperature such as near fire or other heat sources.
*Must not be installed in locations directly exposed to sunlight or reflected light source.


*Maximum performance, actual data rates, and coverage will vary depending on network conditions and environmental factors.
*Actual viewing resolution and frame rate of network cameras depend on connection speed.
*Product specifications and design are subject to change without notice.
